MIL-DTL-18045G
Construction of type I preserver - Continued.
TABLE II.
Seam
Stch
stch
Stch
No.
Operation
type
type
inch
17
Set collar in neck opening (slide
fastener tongue closed will finish
on right side):
A. Place collar between front and
301
SSa
8/10
back sections of vest, stitch-
ing through all four pieces,
approximately 4-1/2 inches of
front to shoulder section.
Continue stitching with two ply
for length of front and back of
collar of 4 pieces or plies of
fabric approximately 4-1/2
inches of neck section.
B. Single needle stitch on collar
301
SSa
8/10
I/A/W premarked locations form-
ing a retaining pocket when
foam is inserted.
C. Bartack 1/2 inch both edges of
301
Bartack
8/10
above stitch patterns.
18
Top stitch rest of fronts 1/8 inch
301
SSc
8/10
from edges.
19
Slot for large D-ring:
A. Cut slit I/A/W drawing and
8/10
location to inside and outside
jacket sections.
B. Fold four edges 3/8 inch inward
8/10
to form a 3/4 inch X 3-3/4
inches rectangular opening
through both inner and outer
jacket.
C. S/N four sides (4 plies) 1/16
301
SSc
14/20
inch from edges.
D. S/N angle tack stitches in all
301
SSa
6/8
four corners for reinforcement.
20
S/N stitch across back above D-ring
301
SSa
8/10
slot I/A/W premarked locations,
stitching inner and outer jacket
together.
9
