MIL-DTL-18045G
Construction of type II preserver - Continued.
TABLE III.
Seam
Operation
Stch
stch
Stch
No.
type
type
inch
B. Stitch front starting 3/4 inch
301
SSa
8/10
from shoulder seam.
8
Cut 2 pieces webbing 1-1/8 inches
301
EFb
8/10
wide X 12 inches long:
A. Turn one end doubled 1/4 inch
and stitch 1/8 inch from edge
and back lock stitch.
9
Closing front of vest, both sides:
A. From shoulder seam starting 3/4
301
SSa
8/10
inch down, stitch 1/2 inch seam
to premarked notch.
B. Insert 1-1/8 inches X 12 inches
301
SSj
8/10
jacket tie tape, continue to
stitch to 2nd notch (backtack
locking stitch), leave opening
for installing slide fastener.
10
Installing left and right side
slide fasteners:
A. Place slide fastener (open
301
LSb
8/10
position) from bottom. Turn
under fabric 1/2 inch and
stitch 1/4 inch from folded
edge (right side).
B. Repeat on opposite (left side).
301
LSb
8/10
C. S/N reinforcing stitches to
301
8/10
top and bottom of both slide
fasteners.
11
Slider protective patch:
A. Protective patch cut from base
fabric with top edge on
selvage.
B. Fold under remaining three
301
LSd
8/10
sides 1/4 inch and topstitch
at bottom of slide fastener
I/A/W premarked locations.
12
Installing neck slide fastener:
A. Stitch fastener to neck area
301
Lsb
8/10
with opening to close when
slide fastener is in closed
position on right side.
13
