MIL-DTL-18045G
Construction of type I preserver - Continued.
TABLE II.
Seam
Stch
stch
Stch
No.
Operation
type
type
inch
25
Chest strap (1 each):
A. Cut webbing 1 inch X 63 inches
long.
B. Turn under 2 inches forming
301
Box-X
8/10
loop for D-ring and Box-X
3/4 inch X 1-1/4 inches on left
end of webbing.
C. On opposite end (right side)
301
Box-X
8/10
weave webbing with 1 inch
slide and snaphook turn or fold
end to form loop 2-1/2 inches
and boxstitch-X, 3/4 inch X 3/4
inch.
26
Front leg straps (2 each):
A. Cut webbing 1 inch X 7 inches
(2 each).
B. Fold under one end of webbing
7/8 inch then form a loop with
2 each D-rings inserted inside
allowing both ends of webbing
to meet.
C. Stitch both front leg straps to
301
Box
8/10
premarked areas with box-X
stitch
stitch 3/4 inch X 1-1/2 inches.
-X
27
Back leg straps (2 each):
A. Cut webbing 1 inch X 48 inches
(2 each).
B. Press ball-tip to each 48
inches webbing.
C. Fold opposite end of webbing
301
Box
8/10
7/8 inch on itself and stitch
stitch
to premarked locations with
-X
boxstitch-X, 3/4 inch X 1-1/2
inches.
28
Visual inspections:
A. Thread breaks, skips, loose
ends.
B. General appearance.
11
