MIL-L-24778(SH)
TABLE II.
Construction.
Stch
Seam/
Stch\
Operation
Thread
No.
type
S tch
in
ndl
bob/lpr
type
Make Bladder.
1.
(a) Heat seal the inflation manifold
device to the back side of the front
ply of the bladder so that the infla-
tion assembly projects out through the
face according to the mark on the blad-
der marker - front view.
(b) Apply an identification label to
the back right side of the inflation
bladder - placement as shown on bladder
marker-back view.
(c) Apply an inspection record label to
the back left side of the inflation
bladder - placement as shown on bladder
marker-back view.
(d) Apply reflective tape to five loca-
tions on front ply of bladder, using
specified adhesive, according to marks
on bladder marker - front view.
(e) Apply pile portion of fastener to
four locations on front ply of bladder,
using suitable adhesive, according to
marks on bladder marker - front view.
(f)- Heat seal the oral inflation tube
to right side of front according to
mark on bladder marker - front view.
(g) Apply holder for C02 cylinder On
back ply of bladder using a suitable
adhesive, according to mark on bladder
marker - front view.
(h) Heat seal the blast patch to the
back side of the back ply of bladder,
using suitable adhesive according to
marks on bladder marker - back view.
8
