MIL-L-24778(SH)
Construction (cent'dl.
TABLE II.
stch/
Seam/
Thread
Stch
Operation
No.
in
stch
type
ndl
bob/lpr
type
8-12
301
EFa -1
(f) Form a 5/8 inch hem on mirror
pocket.
LSbj -1
8-12
301
(g) Using elastic webbing, form a loop
for light battery and attach to back of
back ply of casing according to marks
on bladder casing marker pattern.
Stitch across the width of the loop.
(h) Attach four grommets to each of
two 4-1/2 inch lengths of 1-1/2 inch
webbing.
Attach 2 grommets to a 2-1/2
inch length of 1-1/2 inch webbing.
(i) (Optional) Baste grommet piece in
place on each side of back casing,
according to marks on bladder casing
marker pattern.
Assemble vest.
7.
(a) (Optional) Baste slide fastener to
each front according to marks on
Raschel knit vest marker pattern.
8-12
301
LSak-
(b) Join front ply of casing, vest,
2(a)
and back ply of casing along inside
edge with a 1/2 inch seam, simultane-
ously catching the slide fastener tapes
and grommet pieces.
8-12
301
LSak-
(c) Turn front ply against the seam
2(b)
allowance and edgestitch, 1/8 inch from
folded edge.
301
LSbj -1
8-12
(d) Stitch hood to back of front ply
of casing, across the width of the
hood, matching marks on Raschel knit
vest marker pattern.
8-12
301
LSbj -1
(e) Attach back ply of casing to vest
according to marks on Raschel knit vest
marker pattern.
16
