MIL-L-24778(SH)
Construct ion (cent'd~.
TABLE II.
Thread
Stch/
Seam/
Stch
No
Operation
ndl
in
stch
type
bob/lpr
type
8-12
LSbj -1
301
(j) Stitch reflective tape to outside
of the hood according to marks on hood
casing marker pattern.
EFb-1
Bar-
(k) Using a 12 inch long piece of 1-
tack
inch bartack webbing, make a hood strap
by forming a 3 inch loop with raw edge
turned under and bartack with a 3/4
inch bartack.
EFb-1
Bar -
(1) Attach remaining unfinished end
tack
of strap to center front over center
Se-
seam with raw edge turned under.
cure to hood with a 3/4 inch bartack
The strap shall finish 8 + 1/2 inches
long.
Make bladder casing.
6.
8-12
EFd- 1
503 or
(a) Overedge inner raw edges of back
504 or
and front plies of bladder casing.
602
8-12
BSC-1
301
(b) Bind bottom and outer raw edge of
each ply of bladder casing.
8-12
LSbj -1
301
(c) Attach hook portion of fastener
cape to the back of the front ply of
the bladder casing on the bottom and
outer edge, with the outer edge of the
tape even with the outer edge of the
Stitch 1/8 inch from outer
binding.
edge .
8-12
LSbj -1
301
(d) Attach loop portion of fastener
tape to the back of the back ply of the
bladder casing on the bottom and outer
edge, with the outer edge of the tape
even with the outer edge of the bind-
Stitch 1/8 inch from outer edge.
ing.
8-12
301
LSbj -1
(e) Attach hook portion of fastener
tape in two locations to the back of
the front ply according to marks on
bladder casing marker pattern.
15
