MIL-L-24778(SH)
Construction (cent'd) .
TABLE II.
Stch
Thread
Stch/
Seam/
Operation
No.
ndl
in
stch
type
I
type
bob/1pr
8-12
LSbj -1
301
Turn under bottom
of pocket 3/8
(o)
Attach sides and
bottom of poc-
inch.
ket, leaving the tunnel
open on the
Backstitch each
end of
sides .
stitching.
EFB-1
Bar-
(p) Place vertical bartacks at each
tack
end of tunnel opening, maintaining
opening of approximately 1-3/4 inches.
8-12
LSbj -1
301
(q) Attach buckle and strap assembly
to front of vest, according to marks on
Raschel knit back pattern. The female
portion of the buckle shall be on the
right front, with the male portion on
The buckle portion
the left front.
The
extends beyond the vest assembly.
end of a 46 inch long by 1-1/2 inch
wide webbing shall be inserted through
the buckle, the webbing folded back
approximately 1-1/2 inches, and
attached to the vest by stitching a 3/4
x 1 inch cross-boxstitch through all
Insert webbing through tunnel,
plies .
smoothing out webbing and vest. At
side seam, attach webbing to vest, with
a 3/4 x 1 inch cross-boxstitch.
8-12
EFb-1
301
Insert webbing through the buckles
(r)
(op. 4 h), and return to front of vest
Fold unfinished
through the tunnel.
end of webbing under against itself,
and secure with a 3/4 x 1 inch cross-
boxstitch.
8-12
LSbj -1
301
(s) With pocket flap in open position,
stitch flap to vest according to marks
on Raschel knit front marker, stitching
1/8 inch from folded edge. The right
flap has an indentation on the front
portion of the flap (closest to front
opening of vest) .
13
